Canique Climat Pro can read temperature and humidity from an external wired sensor and transmit this data wirelessly to a base station.
You additionally need either
a) a Canique Gateway (base station) or
b) a Raspberry Pi + a Canique Radio Hat (base station)
to use this device.
Compatibility
Compatible with:
- Measuring probe for temperature and humidity
- Measuring PCB for air temperature and humidity without enclosure
Specs
- Frequency band: 868 MHz
- Range: up to 400 meters without obstacles
- Hardware Revision: 1.1.x
- Battery life time: 10-20 years
- Measurement/Transmission interval: 30 seconds (changeable upon request)
- PCB dimension: 84 x 25 mm
- Drill hole size for screws: M2
Screw terminal
- 4 pin terminal for I2C interface with VCC, GND, SDA, SCL
- integrated 2k pullup resistors for SDA/SCL
- supports wires with AWG 26-18
- supports 4-5 mm stripped wires
- 2.54mm pitch
- M1.6 screws
- supports up to 2m cable length (max 400pF)
Battery
The battery (1 AA battery) is not included, but can be ordered separately in our shop:
- Energizer Industrial LR06 Batterie: 10 years shelf life
- Energizer Ultimate Lithium Batterie: 20 years shelf life
What you get
- Canique Climat Pro with installed internal antenna and screw terminal
